Thicker Spring And More Powerful
The Kailh BOX Heavy Switch is the heavy version of the standard Box switch. It features a thicker spring and provides a more powerful and heavier typing experience. It’s great for those who love a strong trigger force when pressing the keys.
Linear, Tactile, And Clicky
They come in 3 colors: pale blue, dark yellow, and burnt orange. Available in your choice of linear, tactile, and clicky switches.
Double Dustproof & Waterproof Structure
This switch's dust wall design and box structure protect it from dust, and water, and can guarantee this switch to last about 80 million strokes.
High Compatibility 3-Pin Design
This 3-Pin switch's base is engineered with a hollowed-out light position design to offer SMD-LED light compatibility and incorporates an MX stem structure to be compatible with most mechanical keyboards on the market.
Excellent Backlight Effect
This switch’s transparent cover is made of PC material that allows for a vibrant backlight effect and is great for showcasing the RGB lights.
Product Structure
Feature And Specs
| Name | Pale Blue Switch |
|---|---|
| Type | Clicky |
| Operation Force | 60±15 gf |
| Pre-travel | 1.8±0.4 mm |
| Return Force | ≥15 gf |
| Total Travel | 3.6±0.3 mm |
| Sound Level | Loud |
| Operation Life | Up to 80M cycles |
| Suitable For | Typist |
| Name | Burnt Orange Switch |
|---|---|
| Type | Tactile |
| Operation Force | 60±15 gf |
| Pre-travel | 2.0±0.4 mm |
| Return Force | ≥15 gf |
| Total Travel | 3.6±0.3 mm |
| Sound Level | Medium |
| Operation Life | Up to 80M cycles |
| Suitable For | Midway gaming/office |
| Name | Dark Yellow Switch |
|---|---|
| Type | Linear |
| Operation Force | 70±10 gf |
| Pre-travel | 1.8±0.4 mm |
| Return Force | ≥15 gf |
| Total Travel | 3.6±0.3 mm |
| Sound Level | Low |
| Operation Life | Up to 80M cycles |
| Suitable For | Gaming/office |
| Product Name | Kailh BOX Heavy Switch |
|---|---|
| Stem | POM |
| Top Housing | PC |
| Bottom Housing | Nylon PA66 |
| Contact | Composite gold |
| Spring | Spring steel |
| Protecting Cover | Nylon PA66 |
| Slider | POM |
| Pins | 3-Pin |
| Factory Pre-lubed | No |
| SMD LED Support | Yes |
Compatible Keyboard:
Any K series (Gateron Mechanical Hot-Swappable or Keychron Mechanical Hot-Swappable versions only), K Pro series (Normal-profile versions only), C and C Pro series (Hot-Swappable versions only), V series, Q series and Q Pro series Keychron keyboards.
